Worm Gear Reducers SV / ISV Series
Worm Gear Reducers SV / ISV Series
Worm gear drive systems offered for drive systems with low moments and regular loads stand out with their light, high-strength, modern-designed bodies as well as their quiet operation.
Features Of Worm Gear Reducers SV / ISV Series:
- They are worm gear reducers with 90° between the input and output axis.
- With a single body, the connection from the foot and flange is available.
- The body has a rigid structure and is suitable for heat transfer.
- System strength calculations are made in accordance with ISO, DIN, and NIEMANN standards.
- Different input options are available (PAM B5, PAM B14, ...).
- Different output options can be offered (Shaft output, Hollow shaft, ...).
- Different connection accessories are available (B5 flange, B14 flange, Torque arm, ...).
- Worm screws are made of 16MnCr5 cementation steel, impellers are made of CuSn12Ni-C bronze.
- Bodies, ADC-12 aluminum injection is used up to 105 body size.
- High-quality bearings and sealing elements are used.
- Special requests of the customer can be met.
