Shaft Mounted Helical Gearboxes P Series

P series gearboxes, developed for belt-pulley, chain-driven elevator conveyor systems, and drive systems working in difficult areas, come to the fore in terms of ease of maintenance.

Features of Shaft Mounted Helical Gearboxes P Series:

• They are helical gear reducers with parallel axis input and output.
• The body has a rigid structure and consists of two parts.
• System strength calculations are made in accordance with ISO, DIN, and NIEMANN standards.
• The drive is made with a free input shaft.
• Different output options can be offered (Hole shaft, Conical compression, ...).
• It is mounted with the help of a torque arm.
• The bodies are produced as ductile iron (GGG 40-50) and cast iron (GG 20-25).
• Gears are manufactured from forged and 21NiCrMo2 case-hardened steel.
• High-quality bearings and sealing elements are used.
• Special requests of the customer can be met.
