Planetary Gearboxes PL/PLB Series

PGR Drive Technologies planetary gearboxes are the solution in drive systems with heavy and variable loads, with their compact and modular structure of up to 850000 Nm torque values, with PTO, IEC, and splined shaft input options, offering high bonds in small volumes.

Features of Planetary Gearboxes PL/PLB Series:

• They have geared units with coaxial input and output or a 90° axis angle.
• There are foot and flange connection options.
• The body has a rigid and modular structure.
• Compared to other gearboxes, higher torque values ​​can be met with smaller body dimensions.
• System strength calculations are made in accordance with ISO, DIN, and NIEMANN standards.
• Different input options can be offered (IEC, Hydro motor connection, Servo motor connection, ...).
• Different output options can be offered (Shaft output, Conical compression, DIN form slider, ...).
• The bodies are produced as spheroidal (GGG 50-60).
• Gears are manufactured from forged and 21NiCrMo2 case-hardened steel.
• High-quality bearings and sealing elements are used.
• Special requests of the customer can be met.
