Helical Gear Reducers PA/PF Series

In drive systems where a wide range of bonds and a maximum output torque of 26900 Nm are required, service is offered with foot connection (PA) and flange connection (PF) options.

Features of Helical Gear Reducers PA/PF Series:

• They are helical gear reducers with parallel axis input and output.
• There are body options with foot and flange connections.
• The body has a rigid structure.
• System strength calculations are made in accordance with ISO, DIN, and NIEMANN standards.
• Different input options can be offered (Motor coupled, IEC, PAM, W, Servo motor connected, ...).
• Different flange sizes are available for B5 connections.
• The bodies can be produced as spheroid (GGG 40-50) and gray (GG 20-25).
• Gears are manufactured from forged and 21NiCrMo2 case-hardened steel.
• High-quality bearings and sealing elements are used.
• Special requests of the customer can be met.
